Power Efficiency
Up to four displays at 3840 x 2160 with performance to match.
Innovative Design
Designed, manufactured and supported in the UK with a fanless design for increased uptime and reliability.
Security
The DX1500 provides optimal performance for various use cases.
Designed for security and reliability
The DX1500 and DX1700 are engineered to a high standard with a fanless design for increased uptime and reliability, to empower users to reach their full potential without fear of hardware outage. A secure solution which would meet an organisation’s zero trust requirements, you can trust your data is protected.
Security features include: Approved for accessing classified information up to SECRET using Becrypt Paradox SErnrnSecure device remote attestation and user authentication using centrally-managed credentials and multi-factor authentication including YubiKey USB security device. Multiple chassis intrusion switches to detect casework removal and optionally erase device in the event of tampering
REQUEST A QUOTE
Specification
Form Factor
Compact Desktop – 230mm x 133mm x 35mm
Processors
Intel 13th Gen ‘Raptor Lake’ Core CPUs: U300, i3-1315U, i5-1335U and i5-1345U
Thin Client OS
Becrypt Paradox and Paradox SE, IGEL OS, Stratodesk NTOS
General Purpose OS
Microsoft Windows 11 Pro
Cooling
Passive air cooled, fanless design
Mount options
Standard VESA mount and specific mounting accessories available
Display outputs
Four DisplayPort 1.4 video outputs supporting up to 3840×2160 on four simultaneous displays or 5120 x 2160 on two displays.
Dual Network connections
Copper RJ45 10/100/1000 Mbit/s SFP Module supporting 1000Mbit/s LR and SR Fibre and copper
SFP Module supporting 1000Mbit/s LR and SR Fibre and copper
TPM 2.0 compliant
FIPS-certified Firmware TPM or TCG-certified Discrete hardware TPM
Operating Conditions
5 degC to 35 degC ambient temperature
Power
Typ. 10W in-use, 1W standby. Universal AC power with external PSU
Security
Strong encryption and authentication including 256-bit AES and NSA Suite-B
USB connections
Rear – Two USB-C 3.0 + Two USB-A 3.0 Front – Two USB-A 2.0
Memory and storage
Up to 16GB RAM, Up to 256GB local SATA or NVMe flash storage
Compliance
TAA Compliant, Safety, EMC: EN55032 and EN55035 Safety: UL62368-1
